Features

The DeionX DC PowerBox sets a new standard for flexible, reliable, AC/DC power systems for Electro Deionization applications.It is a unique design. Therefore, there is no need to enter the high power compartment for measuring the individual current of each EDI stack
  • Programmable relay with one Digital Control Panel for each voltage part;
  • Over all system control;
  • Voltage and current setting (0-10 V or 0/4-20 mAmp) will replace potential meter;
  • Actual voltage and current reading (0-10 V or 0/4-20 mAmp) for external use;
  • Common Fault Alarm;
  • Fault reset button;
  • Alarm information text;
  • On/Off by external potential free contact;
  • Potential free contact Rectifier in service;
  • Potential free contact Power on/off;
  • Potential free contact Alarm/Fault;
  • Main fuses as required;
  • Separate fuses for each rectifier;
  • Separate fuse for control power 24VDC;
  • Temperature monitoring for each rectifier;
  • Outgoing fused feeders for each single EDI stack;
  • Door interlocked fused disconnect switch;
  • The power supply contactor will open in the event of over temp., electronic trip;
  • Temperature monitoring for the rectifier;
  • Emergency stop;
  • Standard Adhesive warning stickers High Power on door.
DeionX PowerBox designed for demanding applications.Common controls are shared across all platforms.The DeionX PowerBox Switch Mode Power Supplies are specifically designed to be used for Electro Deionisation (EDI). During the last 20 years DeionX engineers reviewed and tested many power supplies. They selected these power supplies as a reliable and simple solution for large scale EDI applications. Over the years, the combination of the DeionX PowerBox with E-Cell or Ionpure EDI has proven to be efficient and cost effective on many ultrapure water systems.In addition to EDI systems, DeionX PowerBox can be used for many other applications like:
  • Electro Separation Technologies as:
    • Electro Dialysis (ED);
    • Electro Dialysis Reverse (EDR);
    • Electro Deionization (EDI).
  • Modern electrochemical processes;
  • Any industrial application that requires stable DC power.
";}i:2
DeionX PowerBox selected for Electro Deionisation applications:
Electrical data
Mains Voltage  EUUSA3 x 400 VAC ± 10%, 47-63 Hz
3 x 460 VAC ± 10%, 47-63 Hz
Mains CurrentUp to 225 Amp
Mains PowerUp to 155 kVA
Nominal DC Voltage300 VDC400 VDC500 VDC
Nominal DC CurrentUp to 415 Amp
Control VoltageTo be specified
Efficiencyup to 90%
Ripple< 3% referred to nominal values
Adjustment ranges0 to 100% of Nominal output
Set Voltage Value0...10 VDC or  0/4...20 mA DC
Set Current Value0...10 VDC or  0/4...20 mA DC
Control Accuracy±1% referred to nominal values
CoolingForced air-cooled
Ambient Temperature0 to 45 ⁰C
Dimensions W / D / H600 / 800 / up to 1800 mm
WeightDepending on model
Protection gradeIP23 or NEMA3R
";
